Alu Alu PVC Tablet Blister Packer Machine

About Alu Alu PVC Tablet Blister Packer Machine

Alu-Alu, PVC and tablet blister packers form, fill and seal tablets, capsules and hardware into pharma- and retail-grade blisters. They handle Alu-PVC, Alu-Alu and card-backed formats at up to 150 cycles/min with GMP-compliant coding. CECLE supplies 9 blister packaging machines.

How to Choose

  • Select pack format: Alu-PVC for standard pharma, Alu-Alu for maximum moisture/light barrier, or Card-PVC for retail carded packs.
  • Match output: 10–25 cycles/min for lab/small batch, 25–60 for mid volume, 60–150 for high-volume pharma lines.
  • Confirm max forming area and depth (15–26 mm typical, customizable) for your tablet/capsule size.
  • Check material widths: PVC reel 0.15–0.5 mm, PTP aluminium foil 0.02–0.035 mm, and GMP/CE certification.
  • Consider servo drive, automatic feeding, batch coding and rejection for compliance and labor savings.

Model Selection Guide

The models below are real CECLE products in this series. Contact us or see doc.cecle.net for full specifications and a quote.

Model Description
MTBP-180 Benchtop manual lever + electric-heat blister machine; no air compressor; 5–8 pcs/min. Lowest cost for small-batch sampling without air supply.
TBP-180 Benchtop pneumatic semi-auto blister machine; needs 0.6–0.8 MPa compressor; 5–10 pcs/min.
ETBP-180 Benchtop fully-electric auto blister machine with built-in foil unwinder; no compressor; 10–15 pcs/min; for printed foil.
BP-180 Floor-standing pneumatic + foot-pedal semi-auto; needs compressor; 5–10 pcs/min.
CP-180 Floor-standing pneumatic + auto foil unwinder semi-auto; needs compressor; 5–10 pcs/min.
DP-180 Floor-standing PLC + stepper + photoelectric registration semi-auto; needs compressor; 5–10 pcs/min; color-foil & batch coding.
DPP-80 Compact full-auto flat-plate blister machine, PLC touchscreen; forming 105×70 mm; 10–33 cycles/min.
DPP-150 Mid full-auto flat-plate, PLC touchscreen + variable speed; forming 130×100 mm; 10–44 cycles/min.
DPP-260 Large full-auto flat-plate; forming 250×120 mm; 15–45 cycles/min; wide-board high-speed continuous.
DPP-140E Dual-function Alu-Alu cold-form & Alu-Plastic thermoform full-auto; forming 140×120 mm; for space-limited pharma.
DPP-250E Dual-function Alu-Alu cold-form & Alu-Plastic thermoform full-auto; forming 250×120 mm; water-cooled mold + vision reject.

FAQ

Q: Alu-Alu or Alu-PVC blister packer?
A: Alu-PVC is standard and cost-effective for most tablets; Alu-Alu adds an aluminium backing for superior moisture, light and oxygen barrier—ideal for sensitive or high-value medicines.

Q: What output can a tablet blister packer reach?
A: Flat-plate and roller models run about 2,000–14,000 blisters/h; servo lines reach 60–150 cycles/min depending on format and product.

Q: Does the machine handle capsules and shaped tablets?
A: Yes—multi-feeding systems accommodate tablets, capsules, softgels and special shapes; contact CECLE with your product and plate size for a matched mold and quote.
